Standard LNA Specifications
| Image | SKU | Min Freq (MHz) | Max Freq (MHz) | P1dB (dBm) | Gain (dB) | NF (dB) | Additional Specs | Voltage (V) | Dimensions (mm) | Action | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
0.1-1000MHz LNA |
|
0.1 | 1000 | 5 | 20 | 4.0 | / | 6 | 30x25x12 | View Details |
|
0.1-20GHz LNA |
|
100 | 20000 | 17 | 24 | 5.0 | / | 15 | 30x25x15 | View Details |
|
1-26GHz LNA |
|
1000 | 26000 | 10 | 32.5 | 3.3 | / | 15 | 30x20x10 | View Details |
|
10-2000MHz (20dB) |
|
10 | 2000 | 10 | 20 | 6.0 | / | 6 | 30x25x12 | View Details |
|
10-2000MHz (40dB) |
|
10 | 2000 | 10 | 40 | 6.0 | / | 6 | 50x25x12 | View Details |
|
20-3000MHz LNA |
|
20 | 3000 | 15 | 20 | 2.7 | / | 6 | 30x25x12 | View Details |
|
400-3000MHz LNA |
|
400 | 3000 | 21 | 20 | 1.5 | / | 6 | 30x25x12 | View Details |
|
50MHz-10GHz LNA |
|
50 | 10000 | / | 20 | 2.0 | Power Diss. ≤ 2 W | 6 | 30x25x12 | View Details |
|
250-700MHz LNA |
|
250 | 700 | / | 27 | 3.5 | Max Input: ≥ 10 dBm | 12 | 50x25x12 | View Details |
Low Noise Amplifier (LNA) Manufacturing Reality
| What Engineers & Integrators Actually Care About | Our Real Hardware Verification & Facts |
|---|---|
| Is your Noise Figure (NF) data real or fabricated? | We don't guess or use AI simulation numbers. Every single low noise amplifier module undergoes strict noise parameter calibration via Keysight N8975A Noise Figure Analyzers. Your shipment includes an individual testing report showing the exact NF curve matching the serial number. |
| Will the highly sensitive LNA burn out from input overload? | Receiver front-ends are fragile. We offer optional integrated high-speed RF limiters built directly into the input port. This protects your LNA from unexpected high-power Tx leakage or ambient co-site interference without compromising the low noise figure. |
| Do you support low MOQs for receiver prototyping? | We know SATCOM, telemetry, and phased-array radar testing start with small engineering batches. We support 1-unit sample evaluation runs. No forcing commercial volume MOQs during your design-in phase. |
| Will I get damaged modules due to poor packaging? | Small coaxial components require precision handling. We package our LNA modules in customized anti-static foam slots inside 5-layer hardened corrugated cartons. They are fully shielded against both ESD and port transit drop shocks. |
Need an RF LNA Sample or a Custom Frequency Design?
Skip the generic forms. Send your required Frequency Range, Target Noise Figure (NF), and Gain straight to our laboratory team.
